Z5260 Microinjection Pump

In the operation of brain stereotaxic instruments, microinjection on animals is often required. The automatic microinjection pump is easy to use: directly install the syringe barrel to the holder, and control the precise movement of the syringe piston through the microcomputer-controlled drive unit to inject or withdraw liquid from experimental animals directly, avoiding errors caused by the catheter method.

The Z5260 microinjection pump, featuring a high-definition touch screen operation and Ditronstep micro-step control system, is a device for precisely controlling and delivering micro-volume liquid drugs or solutions. It is usually used with brain stereotaxic instruments or micromanipulators in the medical field, especially in clinical medicine, laboratory research, drug research and development and other fields. This injection pump is compatible with most imported and domestic micr

osyringes (0.5ul-100ml), with a stroke resolution of 0.0625μm/μstep, a linear velocity range of 0.08μm/min ～160mm/min (flow rate = linear velocity × inner cross-sectional area of syringe), and a maximum propulsion distance of 150mm.

Functional Features

1. Working Modes: Perfusion, Extraction, Perfusion/Extraction, Extraction/Perfusion, Continuous, Multiple Perfusion
2. Touch Display: 5-inch high-definition touch screen, simple, clear, easy to understand and operate
3. Language Options: Chinese and English, 2 languages available
4. Online Speed Adjustment: Adjust the current flow rate without stopping during operation
5. Calibration Function: Supports syringe calibration and stores calibration parameters
6. Syringe Selection: Built-in main models of major domestic and foreign manufacturers for selection, and supports customization
7. Parameter Setting: Liquid volume, flow rate, perfusion time, extraction time, interval time, perfusion times can be set and stored
8. Power-on Operation: Stores current dynamic operation parameters when power is off, and resumes operation after power is restored
9. Prompt Function: Real-time display of available Max/Min flow rate; dynamic display of operation parameters
10. Reminder Function: Audible alarm when running to the set target liquid volume
11. Thrust Setting: Appropriate thrust can be set according to the specifications of each syringe
12. External Control Function: External level or pulse signal to realize start-stop control
13. Communication Control: RS485/USB optional, touch setting of address and baud rate
14. Status Output: Start-stop and direction status output

Technical Parameters

1. Number of Channels: Single Channel
2. Working Modes: Perfusion, Extraction, Perfusion/Extraction, Extraction/Perfusion, Continuous, Multiple Perfusion
3. Maximum Stroke: 150mm
4. Accuracy: <1%
5. Repeatability: Error ≤±0.05%
6. Syringe Specification: 0.5μL～100mL
7. Linear Thrust: ≥160N
8. Linear Velocity Range: 0.08μm/min ～160mm/min
9. Step Resolution: 0.0625μm/μstep
10. Applicable Power Supply: AC 100V～240V  50/60Hz  30W
11. Working Environment: Temperature: 0～40℃  Humidity: 20%-80% RH without condensation
12. Storage Environment: Temperature: -10～60℃  Humidity: 20%-80% RH without condensation
13. Protection Grade: IP31
14. Product Dimensions (mm): 256*190*146 (mm)
